category:
Electric Motors
height:
12.5
length:
12
manufacturer:
Century
mpn:
D0346
subcategory:
AC Motors - NEMA
type:
HVAC - R Motors
weight:
8.05
width:
10.38
Product Overview
- OEM Direct Replacement Motor
- 3.3" Diameter
- Permanent Split Capacitor (PSC); Capacitor Required: 12.5 Mfd-370 Volts (Supplied with Motor)
- Thermally Protected
- Open Shaft End End-Frame and Opposite Shaft End End-Frame, Enclosed Shell Shaft End and Open Shell Opposite Shaft End, Air Over
- Class B Insulation, 40°C Ambient
- Sleeve Bearing
- 3/8" Diameter Shaft with Flat
- 10" Leads with Plug Assembly
- Lug Mount Shaft End
Additional Information
Thermal ProtectionThermally Protected
Speed1550 rpm
Current2.90 A
Number of Speeds2
Ambient Temperature40 °C
ULRecognized
Insulation ClassB
CSAN
Weight8.05 LB
Country Of originMexico
Output HP1/4 Hp
Output KW0.19 kW
Service Factor1
Frame3.3
EnclosureOpen Air Over
DutyAir Over
Electrical TypePermanent Split Capacitor
Poles4
RotationClockwise Shaft End
MountingLug
Drive End BearingSleeve
Opp Drive End BearingSleeve
Frame MaterialSteel
Shaft TypeFlat
Frame Length4.68 in
Shaft Diameter0.375 in
Shaft Extension5.44 in
CEN
Starting MethodAcross The Line
