Product Description
ICM - ICM2918
DETAILS:
Universal Intermittent Pilot Ignition Control Module.Provides ignition sequence, flame monitoring and safety shutoff for single/dual rod intermittent pilot control applications
- For gas fired furnaces, boilers and other heating applications
- Switch selectable pre-purge and ignition trials with permanent lock
- Works with or without vent damper connected
- Works with both Natural Gas and LP Gas systems
WEIGHT/DIMENSIONS:
5.50 x 4.00 x 2.00
SPECIFICATIONS:
Control voltage: 18-30 VAC @ 50/60 Hz
Trial for ignition: 15 or 90 seconds (switch settable)
Operating temperature: -40°F (-40°C) to 165°F (74°C)
Relative humidity: 5% 95% (non-condensing) at +55°C
Pre-purge time: 0 sec or 30 sec (switch settable)
Green status LED: System status and error codes
Yellow flame LED: Flame presence and flame strength
