category:
Low Water Cutoffs
manufacturer:
McDonnell & Miller
mpn:
172806
subcategory:
Steam
type:
Line Voltage Low Water Cutoffs
weight:
25.7
Product Overview
Features and Benefits
- For commercial and industrial low or high pressure boiler applications
- For boilers of any steaming capacity
- Monel bellows provides corrosion resistance
- Snap action switches for high temperature service
- 1 Single pole, single throw switch for pump control
- 1 Single pole, double throw switch for low water
- Cut-off and alarm actuation
Optional Features
- Manual reset
- 2 Single pole, single throw switches
- 2 Single pole, double throw switches
- Float block
- BSPT threads
- Maximum pressure 150 psi
Additional Information
ApplicationSteam Boilers
SwitchSPDTSPST
Max Pressure150 psi
TypeFloat-StyleCombo
FeaturesSnap Switch
Reset TypeManual
Depth (Inches)13-1/4"
Width (Inches)6"
Length12-7/16"
Electrical Ratings (ALR)44.4 A @ 120 VAC22.2 A @ 240 VAC
Electrical Ratings (AFL)7.4 A @ 120 VAC3.7 A @ 240 VAC
Pilot Duty Rating345 VA
Thread Size1"
Connection TypeThreaded
