category:
Ball Bearings
country_of_origin:
Japan
inner_diameter:
85 mm
manufacture:
Nachi America
mpn:
6217NR
outer_diameter:
150 mm
subcategory:
Deep Groove Ball Bearing
upc:
4991893734522
weight:
3.95
width:
28 mm
Product Description
Because of their versatility, Single-row, Deep-groove Ball Bearings are the most popular of all the ball bearing types. NACHI Deep-groove Ball Bearings are available in a wide range of series defined by the JIS (ISO) standard dimension plan and are also made to meet specialized dimension and configuration requirements.
Features
NACHI Deep-Groove Ball Bearings are availible open, sealed, or shielded. (-2NSE9) = 2 High Performance NBR Contact Seals, (-2NKE9) = 2 High Performance NBR Non-Contact Seals, (ZZE) = 2 Heavy Duty Shields, (-2NSL) = 2 Large Size NBR Contact Seals, (ZZ) = 2 Large Size Shields, (MY) = Brass Cage
Additional Information
ISO Precision Class P0
Snap Ring Yes
Cage Material Steel
Inner Ring Material Steel
Width 28 mm
Bearing Type Deep Groove
Ball Material Steel
Bore Type Cylindrical Bore
Temperature Range [Max] 248 °F
Outer Ring Material Steel
Rolling Element Material Steel
Seals or Shields No
Static Load Rating [Max] 62000 N
Limiting Speed - Grease 4300 rpm
Limiting Speed - Oil 5000 rpm
Dynamic Load Rating 84000 N
EAN or UPC 4991893734522
