category:
Ball Bearings
country_of_origin:
Thailand
inner_diameter:
20 mm
manufacture:
Nachi America
mpn:
6304ZZENR
outer_diameter:
52 mm
subcategory:
Deep Groove Ball Bearing
upc:
4991893762693
weight:
0.32
width:
15 mm
Product Description
Because of their versatility, Single-row, Deep-groove Ball Bearings are the most popular of all the ball bearing types. NACHI Deep-groove Ball Bearings are available in a wide range of series defined by the JIS (ISO) standard dimension plan and are also made to meet specialized dimension and configuration requirements.
Features
NACHI Deep-Groove Ball Bearings are availible open, sealed, or shielded. (-2NSE9) = 2 High Performance NBR Contact Seals, (-2NKE9) = 2 High Performance NBR Non-Contact Seals, (ZZE) = 2 Heavy Duty Shields, (-2NSL) = 2 Large Size NBR Contact Seals, (ZZ) = 2 Large Size Shields, (MY) = Brass Cage
Additional Information
Rolling Element Material Steel
Cage Material Steel
Outer Ring Material Steel
Limiting Speed - Grease 14000 rpm
Temperature Range [Max] 248 °F
Grease Fill Chevron SRI#2
Bearing Type Deep Groove
Width 15 mm
ISO Precision Class P0
Ball Material Steel
Seals or Shields 2 Shields
Dynamic Load Rating 15900 N
Inner Ring Material Steel
Static Load Rating [Max] 7900 N
Snap Ring Yes
Bore Type Cylindrical Bore
EAN or UPC 4991893762693
