Solberg CT-850-250C Inline Straight-Through Vacuum Filter – 2.5" NPSC, 2 Micron Paper Element, Carbon Steel Bucket

Solberg CT-850-250C Inline Vacuum Filter

The Solberg CT-850-250C is a heavy-duty inline straight-through vacuum filter designed to protect vacuum pumps and industrial systems from damaging particulate contamination. Built with a corrosion-resistant cast aluminum top and durable black powder-coated carbon steel bucket, this compact filter delivers reliable airflow performance, low pressure drop, and extended service life in demanding industrial environments.

Key Features

• Inline straight-through vacuum filter design
• 2.5" NPSC threaded inlet and outlet connections
• High-efficiency 2 micron paper filter element
• 99%+ particulate removal efficiency
• Compact construction for installations with limited space
• Corrosion-resistant cast aluminum head assembly
• Black powder-coated carbon steel drop-down bucket
• Integrated internal baffle for optimized airflow performance
• Inlet positioned above the filter element for longer element life
• Easy maintenance with removable bucket assembly
• Designed for medium vacuum service applications

Specifications

• Model: CT-850-250C
• Connection Size: 2.5"
• Connection Type: NPSC / FNPT
• Flow Capacity: 210 SCFM
• Element Flow Rating: 290 SCFM
• Filter Media: Paper Element
• Micron Rating: 2 Micron
• Filtration Efficiency: 99%+ removal efficiency
• Vacuum Rating: Medium Vacuum Service
• Continuous Temperature Range: -15°F to 220°F (-26°C to 104°C)
• Housing Material: Cast Aluminum / Carbon Steel
• Bucket Finish: Black Powder Coat
• Approximate Dimensions: 9" OD x 13" Height
• Approximate Weight: 15–17 lbs
• Replacement Element: 850 Series

Applications

• Vacuum pump systems
• Pneumatic conveying systems
• Vacuum packaging equipment
• Factory automation systems
• Paper processing equipment
• Woodworking operations
• Cement and ash handling
• Wastewater aeration systems
• Central vacuum systems
• Glass and ceramic vacuum applications
• Remote compressor installations

Optional Accessories

• Vacuum gauges
• Gauge and mounting bracket taps
• Swing bolts for heavy-duty environments
• Drain ports
• Extended bucket configurations
• Alternative filter media options
• Reverse pulse configuration

The CT-850-250C inline vacuum filter is engineered to maximize equipment protection while maintaining efficient airflow and low restriction, helping reduce maintenance costs and extend the operational life of industrial vacuum systems.
