Solberg EE-GL915-NW2516 Oil Mist Discharge Filter – NW25 ISO Flange, 0.3 Micron Coalescing Vacuum Pump Exhaust Separator

Product Description

Solberg EE-GL915-NW2516 Oil Mist Discharge Filter

The Solberg EE-GL915-NW2516 is a compact high-efficiency oil mist discharge filter designed for oil-sealed vacuum pumps. It is engineered to capture fine oil fog, mist, and aerosol particles from exhaust streams, helping maintain clean working environments, reduce emissions, and protect surrounding equipment.

This model features a durable carbon steel housing with a corrosion-resistant white powder-coated finish and a high-performance coalescing element. It is designed for continuous-duty operation and includes an integrated backpressure relief valve that protects the vacuum pump in case of excessive differential pressure.

Key Features

• High-efficiency oil mist and aerosol separation from vacuum pump exhaust
• NW25 ISO flange inlet and outlet connections (with 16 mm neck)
• 0.3 micron coalescing filtration media
• 99.97% filtration efficiency for fine oil mist removal
• Integrated backpressure relief valve (opens at approx. 0.5 bar differential)
• Seamless drawn carbon steel housing construction
• White powder-coated corrosion-resistant finish
• Low pressure drop design for stable vacuum performance
• 1/8" NPSC oil drain port for condensate removal
• Vertical installation design for proper drainage

Specifications

• Model: EE-GL915-NW2516
• Series: EE Series Oil Mist Discharge Filter
• Connection Type: NW25 ISO flange
• Rated Flow: ~8 SCFM
• Filtration Rating: 0.3 micron
• Filtration Efficiency: 99.97%
• Operating Temperature: 68°F to 180°F (20°C to 80°C)
• Housing Material: Carbon steel (powder-coated)
• Drain Port: 1/8" NPSC
• Replacement Element: GL915
• Approximate Dimensions: ~119 mm length (varies by configuration)

Applications

• Oil-sealed vacuum pump exhaust systems
• Industrial vacuum and process systems
• Vacuum coating and freeze drying systems
• Semiconductor and electronics manufacturing
• Refrigeration and HVAC evacuation service
• Leak detection and laboratory vacuum systems
• General industrial oil mist recovery applications

Benefits

• Improves air quality by reducing oil mist emissions
• Protects vacuum pumps from damaging backpressure conditions
• Enhances safety with integrated relief valve protection
• Supports stable, continuous-duty operation

The EE-GL915-NW2516 is engineered for precision vacuum applications requiring efficient oil mist separation in an ISO NW25 flange configuration, ensuring clean exhaust and reliable system protection.
