Product Description
The Solberg FT-485P-1000F is a heavy-duty exposed intake filter with weatherhood engineered for high-capacity industrial blowers, compressors, vacuum systems, and pneumatic conveying applications. Designed for maximum airflow and low restriction, this FT Series filter delivers dependable particulate filtration and long-lasting equipment protection in severe-duty industrial environments.
This model features a 10" ANSI flange connection and a high-efficiency polyester filter element rated at 5 microns with 99%+ particulate removal efficiency. The rugged carbon steel housing with corrosion-resistant gray powder coat finish provides superior durability and reliable performance in demanding operating conditions.
Key Features
- Model: FT-485P-1000F
- 10" ANSI flange connection
- Exposed/open element design with weatherhood protection
- High airflow capacity for demanding industrial systems
- Polyester filter media with 99%+ efficiency at 5 microns
- Heavy gauge carbon steel construction
- Corrosion-resistant gray powder coat finish
- Low restriction outlet pipe and center bracket design
- Continuous operating temperature: -15°F to 220°F (-26°C to 104°C)
- Recommended filter replacement differential: 15-20" H2O above initial pressure drop
- Pressure drop graphs available upon request
- Fully drawn weatherhood for outdoor and industrial protection
- Replacement filter element: 485P
- Designed for severe-duty industrial environments
Applications
- Positive displacement blowers
- Side channel blowers
- Piston compressors
- Screw compressors
- Pneumatic conveying systems
- Vacuum pumps and vacuum systems
- Hydraulic breathers
- Waste water aeration systems
- Ash handling systems
- Industrial workshops
- Construction and contractor equipment
- Dock controls
- Envelope manufacturing
- Heavy industrial and severe-duty operations
The Solberg FT Series intake filters are designed to provide superior airflow performance, efficient particulate removal, and extended service life while minimizing maintenance requirements and protecting critical industrial equipment.
