Product Description
The Solberg STS-100C is a compact inline T-style liquid separator designed to protect vacuum pumps and systems from harmful liquids, moisture, and particulate contamination. Built for industrial reliability, it ensures efficient separation of liquid and debris before they can damage downstream equipment.
This STS Series separator features a see-through polycarbonate bowl for easy visual inspection and a stainless-steel float mechanism that helps prevent overflow conditions. The internal baffle design efficiently separates liquids from the airstream, while the rugged cast aluminum head ensures long-term durability in demanding environments.
Key Features
- Inline T-style liquid separator design
- See-through high-impact polycarbonate bowl
- Internal baffle system for efficient liquid separation
- Stainless steel float shut-off mechanism for protection
- Compact design for space-constrained installations
- Corrosion-resistant cast aluminum head
- Designed for vacuum pump protection and extended life
- Easy maintenance and quick inspection capability
Specifications
- Model: STS-100C
- Connection Size: 1 in NPT
- Type: Inline T-Style Liquid Separator
- Flow Capacity: ~25–40 CFM (depending on system conditions)
- Housing Material: Cast Aluminum
- Bowl Material: Polycarbonate (see-through)
- Float Mechanism: Stainless steel safety shut-off
- Operating Temperature: -15°F to 220°F
- Design Pressure: Low pressure / vacuum service
- Configuration: Straight-through inline (T-style)
Applications
- Vacuum pump protection systems
- Soil vapor extraction systems
- Food processing equipment
- Industrial vacuum lines
- Chip and dust processing systems
- Pneumatic conveying systems
- General industrial air/liquid separation
The Solberg STS-100C delivers reliable liquid separation performance with a compact footprint, helping protect vacuum systems from liquid damage while improving overall equipment reliability.
