Product Description
Extend the life of your HVAC equipment, while keeping energy costs at bay, with a U.S. Motors® brand HVAC motor from Nidec Motor Corporation. You can count on our HVAC motors to deliver the power you need to maintain indoor air comfort, reliably and efficiently. Whether you are looking for a high-speed blower motor to drive an air conditioning system or a lower-speed option for heating and air circulation, you will find a reliable U.S. Motors® brand HVACR motor engineered for optimal performance. From the advanced technology of variable speed electronically commutated motors to market-leading NEMA Premium®† efficient motors, U.S. Motors® brand HVAC motors are industry leaders. The extensive U.S. Motors® product line includes HVAC motors for OEMs as well as replacement motors for major OEM equipment. Our online tools will help you find the best HVACR motor for your needs quickly. Whether you want to heat things up or stay cool, your motor search ends here.
Specifications
| HORSEPOWER | 1/15 |
|---|---|
| VOLTAGE | 115-230 V |
| AMPS | 0.65-1.20 |
| RPM | 1550-1625 |
| FREQUENCY | 50/60 Hz |
| LENGTH | 2.20" |
| ENCLOSURE | IP66 |
| SHAFT DIM. | 5/16" x 2-1/2" |
| TYPE | Electronically Commutated |
| SPEEDS | 1 |
| DIAMETER | 3.3" |
| EFFICIENCY | Up to 70% |
| BEARINGS | Ball |
| ROTATION | CCWSE |
| PROTECTOR | Automatic |
| SERVICE FACTOR | 1.00 |
| PHASE | 1 |
| AMBIENT TEMP. | 55°C |
| FEATURE(S) | Class 'A' Insulation, Standard 4 Bolt 10-32 Shaft End Mounting Studs, Robust Ball Bearing System, Aluminum Low Profile Frame, UL/CUL Approved, Includes 27" Cord & 2-Pin Plug, Operating Temperature Range -40°C to +55°C, IP66 Water Tight with all angle Moisture Protection, Dual Voltage: No Connection Change Required |
| WEIGHT (LBS.) | 3 |
