category:
Digital Multimeters
manufacturer:
UEI Test Instruments
mpn:
DM515
Product Description
UEI Test Instruments - DM515 Applications:
- Current measurements
- Measure electrical loads
- Motor or line current
- Measure circuit breakers
- Circuit continuity or specified resistance
- Control voltage or system board voltage checks
- Diode test malfunction/ unbroken paths
- Ambient or surface temperatures
Features:
- Auto ranging
- Auto power off
- Min/Max
- Hold
- 1 ms Fast response Min/Max
- 6’ drop protection
- IP42 ingress protection
- Low battery indicator
- Rubber boot w/ kick stand
- Test lead holders
- High resolution backlit display
- Fused test lead inputs
Functions:
- TRMS: Yes
- AC Volts: 1000V
- DC Volts: 1000V
- AC current (amps): 10A
- DC current (amps): 10A
- AC micro current (amps): 600µA
- DC micro current (amps): 600µA
- DC micro volts: 6µV
- AC micro volts: 6µV
- Capacitance (Farads): 9999µF
- Temperature: -328° to 2462°F
- Continuity: Yes
- Diode: Yes
