country_of_origin:
TW
manufacturer:
US Motors
mpn:
AGL10FL1NB
Features
- Thru-Bolt Pool & Spa Motors
- 5.5" Frame Diameter
- Single Speed Less Rigid Base
Additional Information
PHASETYPE:1_SPLIT PHASE
MOTOR ENCLOSURE:ODP
HORSEPOWER:1
KILOWATTS:0.8
POLES:2
NUMBER SPEEDS:1
RPM:3450
HERTZ:60
VOLTS PRIMARY:115 V
VOLTS :115
FRME :48
SHAFT CODE:Y
STATOR DIAMETER:5.5
STACK:2
MOUNTING:THRU BOLT
MOTOR TYPE:FHP
OPPOSITE END BEARING:6203
SHAFT END BEARING:6203
AMBIENT:40
ROTATION:CCW DRIVE END
SERVICE FACTOR:1
SHIPPING WEIGHT:22
THERMAL PROTECTION:AUTOMATIC RESET
BREAKDOWN TORQUE:55.07
BREAKDOWN TORQUE UOM:OZFT
LOCKED ROTOR TORQUE:24.11
LOCKED ROTOR TORQUE UOM:OZFT
INSULATION CLASS:B
KVA CODE LETTER:K
LOCKED ROTOR AMPS:63.79
FULL LOAD AMPS PRIMARY:12.4
