country_of_origin:
TW
manufacturer:
US Motors
mpn:
AGL15FL1H2
Product Description
US Motors - AGL15FL1H2
Features- Thru-Bolt Pool Spa Motors
- 5.5" Frame Diameter
- Hoffinger® Replacement
- Less Rigid Base
- Class B Insulated
Additional Information
PHASETYPE:1_SPLIT PHASE
MOTOR ENCLOSURE:ODP
POLES:2
NUMBER SPEEDS:1
RPM:3450
HERTZ:60
VOLTS PRIMARY:115 V
VOLTS :115
FRME :48
SHAFT CODE:Y
STATOR DIAMETER:5.5
STACK:2
MOUNTING:THRU BOLT
MOTOR TYPE:FHP
OPPOSITE END BEARING:6203
SHAFT END BEARING:6203
AMBIENT:40
ROTATION:CCW SHAFT END
SERVICE FACTOR:1
SHIPPING WEIGHT:15
THERMAL PROTECTION:AUTOMATIC RESET
BREAKDOWN TORQUE:53.83
BREAKDOWN TORQUE UOM:OZFT
LOCKED ROTOR TORQUE:19.79
LOCKED ROTOR TORQUE UOM:OZFT
INSULATION CLASS:B
KVA CODE LETTER:F
LOCKED ROTOR AMPS:56.32
FULL LOAD AMPS PRIMARY:11.5
