country_of_origin:
TW
manufacturer:
US Motors
mpn:
D13BA2L49
Product Description
US Motors - D13BA2L49
Features- General Purpose
- Single Phase 50 Hz Rated
- Open Dripproof (ODP) Totally Enclosed Fan Cooled (TEFC)
Additional Information
PHASETYPE:1_SPLIT PHASE
MOTOR ENCLOSURE:ODP
HORSEPOWER:.33
KILOWATTS:0.3
POLES:4
NUMBER SPEEDS:1
RPM:1425
HERTZ:50
VOLTS PRIMARY:110/220 V
VOLTS :110
VOLTS 2:220
FRME :48
STATOR DIAMETER:5.5
STACK:1.75
MOUNTING:RIGID
MOTOR TYPE:FHP
OPPOSITE END BEARING:BALL
SHAFT END BEARING:BALL
AMBIENT:40
ROTATION:CCW LEAD END REV
SERVICE FACTOR:1
SHIPPING WEIGHT:22
THERMAL PROTECTION:AUTOMATIC RESET
BREAKDOWN TORQUE:53.81
BREAKDOWN TORQUE UOM:OZFT
LOCKED ROTOR TORQUE:41.3
LOCKED ROTOR TORQUE UOM:OZFT
INSULATION CLASS:B
KVA CODE LETTER:R
LOCKED ROTOR AMPS:42.34
NEMA NOMINAL EFFICIENCY:58
FULL LOAD AMPS PRIMARY:7.1/3.6
SERVICE FACTOR AMPS PRIMARY:7.1 / 3.6
