availability:
In stock
enclosure:
ODP
frame:
56
horsepower:
1.5
mpn:
EB976
phase:
1
rpm:
2800-3600, 1400-1800
voltage:
200-240
Product Description
- 56 C Flange Pool & Spa Motors
- Switchless Design 6.5" Diameter Category "S" & "J"
- Premium Efficient
- Full Service Factor Full Rated Soft Start
Specifications
| Model_Number | R063DML0185013J |
|---|---|
| PRODUCT NAME | 1.5 HP - ODP - 3450 |
| PHASETYPE | 1_PERMANENT SPLIT CA |
| MOTOR ENCLOSURE | ODP |
| HORSEPOWER | 1.5 |
| HORSEPOWER 2 | 0.18 |
| POLES | 2 |
| POLES 2 | 4 |
| NUMBER SPEEDS | 2 |
| RPM | 3450 |
| RPM 2 | 1725 |
| HERTZ | 60 |
| VOLTS PRIMARY | 230 V |
| VOLTS | 230 |
| FRME | 56 |
| SHAFT CODE | C |
| STATOR DIAMETER | 6.3 |
| STACK | 2.75 |
| MOUNTING | C-FACE |
| MOTOR TYPE | FHP |
| OPPOSITE END BEARING | BALL |
| SHAFT END BEARING | BALL |
| AMBIENT | 50 |
| ROTATION | CW LEAD END |
| RUNCAPMFD | 30 |
| RUNCAPVOLTS | 370 |
| SHIPPING WEIGHT | 40 |
| THERMAL PROTECTION | AUTOMATIC RESET |
| BREAKDOWN TORQUE | 129.2 |
| BREAKDOWN TORQUE UOM | OZFT |
| LOCKED ROTOR TORQUE | 8.463 |
| LOCKED ROTOR TORQUE UOM | OZFT |
| INSULATION CLASS | B |
| KVA CODE LETTER | A |
| LOCKED ROTOR AMPS | 49.61 |
| FULL LOAD AMPS PRIMARY | 9.4/3.0 |
