availability:
In stock
frame:
56
horsepower:
1
mpn:
FD1PM2DZYR
phase:
3
rpm:
1400-1800
voltage:
200-240, 440-480, 190, 380-415
Product Description
- Special Application Farm
- Three Phase
- Dust Tight & Auger Duty Motors
- 3-Phase
- Auger Duty
Specifications
| Model_Number | P063DZZ1488015B |
|---|---|
| PRODUCT NAME | 1 HP - - 1725 |
| PHASETYPE | 3_PHASE |
| HORSEPOWER | 1 |
| KILOWATTS | 0.8 |
| POLES | 4 |
| NUMBER SPEEDS | 1 |
| RPM | 1725 |
| RPM 2 | 1425 |
| HERTZ | 60 |
| HERTZ 2 | 50 |
| VOLTS PRIMARY | 208-230/460 |
| VOLTS | 208 |
| VOLTS 2 | 230 |
| VOLTS 3 | 460 |
| VOLTS 4 | 190 |
| VOLTS 5 | 380 |
| FRME | 56 |
| SHAFT CODE | Y |
| STATOR DIAMETER | 6.3 |
| STACK | 2.75 |
| MOTOR TYPE | FHP |
| OPPOSITE END BEARING | 6203 |
| SHAFT END BEARING | 6203 |
| AMBIENT | 40 |
| ROTATION | REVERSIBLE |
| SERVICE FACTOR | 1.15 |
| SHIPPING WEIGHT | 36 |
| BREAKDOWN TORQUE | 280.8 |
| BREAKDOWN TORQUE UOM | OZFT |
| LOCKED ROTOR TORQUE | 164.7 |
| LOCKED ROTOR TORQUE UOM | OZFT |
| KVA CODE LETTER | K |
| LOCKED ROTOR AMPS | 27.7 |
| NEMA NOMINAL EFFICIENCY | 85.5 |
| FULL LOAD AMPS PRIMARY | 3.3-3.2/1.5& 3.5/1.8 |
| SERVICE FACTOR AMPS PRIMARY | 3.3-3.4/1.7 |
