Product Description
- General Purpose
- Three Phase Totally Enclosed Fan Cooled (TEFC)
- World Motor HOSTILE DUTY„¢
- Premium Efficient
Specifications
| Model_Number | GL43 |
|---|---|
| PRODUCT NAME | 15 HP - TEFC-IP54 - 3540 |
| PHASETYPE | 3_PHASE |
| MOTOR ENCLOSURE | TEFC-IP54 |
| HORSEPOWER | 15 |
| KILOWATTS | 11.2 |
| POLES | 2 |
| NUMBER SPEEDS | 1 |
| RPM | 3540 |
| RPM 2 | 3540 |
| RPM 3 | 3520 |
| RPM 4 | 2925 |
| RPM 5 | 2925 |
| HERTZ | 60 |
| HERTZ 2 | 50 |
| VOLTS PRIMARY | 208-230/460 |
| VOLTS | 460 |
| VOLTS 2 | 230 |
| VOLTS 3 | 208 |
| VOLTS 4 | 400 |
| VOLTS 5 | 200 |
| FRME | 254 |
| SHAFT CODE | T |
| MOUNTING | HORZ-FOOTED |
| ASSEMBLY POSITION | F1 |
| MOTOR TYPE | CTE |
| OPPOSITE END BEARING | 6209-2Z-J/C3 |
| SHAFT END BEARING | 6309-2Z-J/C3 |
| AMBIENT | 40 |
| ROTATION | DUAL |
| SERVICE FACTOR | 1.15 |
| STARTCAPMFD | N\A |
| SHIPPING WEIGHT | 269 |
| BREAKDOWN TORQUE | 259 |
| BREAKDOWN TORQUE UOM | PERCENT OF FLT |
| LOCKED ROTOR TORQUE | 200 |
| LOCKED ROTOR TORQUE UOM | PERCENT OF FLT |
| INSULATION CLASS | F |
| KVA CODE LETTER | G |
| LOCKED ROTOR AMPS | 112.1 |
| NEMA NOMINAL EFFICIENCY | 91 |
| FULL LOAD AMPS PRIMARY | 39-35/17.4 |
| SERVICE FACTOR AMPS PRIMARY | 46-40/20.1 |
