Product Description
- Capacitor Start
- General Purpose Single Phase
- Totally Enclosed Fan Cooled (TEFC)
- Rigid Base
- Reversible Rotation
Specifications
| Model_Number | C055KLD4993015B |
|---|---|
| PRODUCT NAME | .5 HP - TEFC - 1725 |
| PHASETYPE | 1_CAPACITOR START |
| MOTOR ENCLOSURE | TEFC |
| HORSEPOWER | .5 |
| KILOWATTS | 0.4 |
| POLES | 4 |
| NUMBER SPEEDS | 1 |
| RPM | 1725 |
| HERTZ | 60 |
| VOLTS PRIMARY | 115/208-230 V |
| VOLTS | 115 |
| VOLTS 2 | 208 |
| VOLTS 3 | 230 |
| FRME | 48 |
| STATOR DIAMETER | 5.5 |
| STACK | 2.25 |
| MOUNTING | RIGID |
| MOTOR TYPE | SER |
| OPPOSITE END BEARING | 6203 |
| SHAFT END BEARING | 6203 |
| AMBIENT | 40 |
| ROTATION | REVERSIBLE |
| SERVICE FACTOR | 1.15 |
| STARTCAPMFD | 440 |
| SHIPPING WEIGHT | 22 |
| THERMAL PROTECTION | NONE |
| BREAKDOWN TORQUE | 76.94 |
| BREAKDOWN TORQUE UOM | OZFT |
| LOCKED ROTOR TORQUE | 108.8 |
| LOCKED ROTOR TORQUE UOM | OZFT |
| INSULATION CLASS | B |
| KVA CODE LETTER | M |
| LOCKED ROTOR AMPS | 41.58 |
| FULL LOAD AMPS PRIMARY | 9/4.3-4.5 |
| SERVICE FACTOR AMPS PRIMARY | 9.6/4.6-4.8 |
