availability:
In stock
frame:
143
horsepower:
1
mpn:
WD1E2A14CR
phase:
3
rpm:
1400-1800
voltage:
200-240, 440-480
Product Description
- Three Phase
- Special Application Washdown
- Totally Enclosed Energy Efficient
- C Face Footless
- BISSC®€ Certified and USDA®€ Approved
Specifications
| Model_Number | P063GBR4454015B |
|---|---|
| PRODUCT NAME | 1 HP - - 1725 |
| PHASETYPE | 3_PHASE |
| HORSEPOWER | 1 |
| KILOWATTS | 0.8 |
| POLES | 4 |
| NUMBER SPEEDS | 1 |
| RPM | 1725 |
| HERTZ | 60 |
| VOLTS PRIMARY | 208-230/460 |
| VOLTS | 208 |
| VOLTS 2 | 230 |
| VOLTS 3 | 460 |
| FRME | 143 |
| SHAFT CODE | TC |
| STACK | 2.875 |
| MOTOR TYPE | FHP |
| OPPOSITE END BEARING | 6205 |
| SHAFT END BEARING | 6203 |
| AMBIENT | 40 |
| ROTATION | REVERSIBLE |
| SERVICE FACTOR | 1.15 |
| SHIPPING WEIGHT | 26 |
| BREAKDOWN TORQUE UOM | OZFT |
| LOCKED ROTOR TORQUE UOM | OZFT |
| KVA CODE LETTER | L |
| NEMA NOMINAL EFFICIENCY | 82.5 |
| FULL LOAD AMPS PRIMARY | 3.4-3.3/1.7 |
| SERVICE FACTOR AMPS PRIMARY | 3.9-3.6/1.8 |
