category:
WELDING SUPPLIES
manufacturer:
Nasco
mpn:
341-0781-0584
subcategory:
GAS CUTTING & WELDING
Product Description
Nasco - 341-0781-0584
| Manufacturer Part Number | 0781-0584 |
|---|---|
| GTIN | 716352007238 |
| Family | Victor SR 450 Series Single Stage Heavy Duty Regulators |
| Manufacturer | Thermadyne |
| Hazmat | N |
| Testing and Approvals | UL Listed; Conforms to CGA E-4 |
| Country of Origin | MX |
| Features | Medium to high gas service capacity Single stage design Stem type seat mechanism Delrin cap bushing for smooth adjustments External self reseating relief valve not designed to protect downstream apparatus |
| Body Material | Forged Brass |
| Depth [Nom] | 5 1/8 in |
| Diaphragm Material | Stainless Steel |
| Diaphragm Size | 3 1/4 in |
| Filter Material | Bronze; Sintered |
| Flow Range | 2- 15 psig |
| Gas Type | Acetylene |
| Gauge Size | 2 1/2 in |
| Height [Nom] | 7 in |
| Inlet Connection | CGA 510 |
| Inlet Pressure [Max] | 3,000 psig |
| Length [Nom] | 7 in |
| Outlet Connection | 9/16 in - 18 (M) |
| Outlet Pressure [Max] | 15 psig |
| Outlet Pressure [Min] | 2 psig |
| Width [Nom] | 7 1/4 in |
| Wt. | 5 1/8 lb |
