manufacturer:
Western Enterprises
mpn:
RS-2-4
weight:
2.1
Product Description
| Manufacturer Part Number | RS-2-4 |
|---|---|
| GTIN | 698944045531 |
| Family | Western Enterprises RS Series Medium Duty Single Stage Regulators |
| Manufacturer | Western Enterprises |
| Manufacturer URL | http://www.westernenterprises.com |
| Hazmat | N |
| Testing and Approvals | UL Listed |
| Country of Origin | US |
| Features | 450 PSIG models have KEL-F seat to accommodate high pressure applications Dual inlet filter system extends regulator life Hydrogen and methane models equipped with pipe away relief valves Nickel chrome plated zinc bonnet |
| Body Material | Machined Brass |
| Diaphragm Material | Neoprene |
| Flow Cap. [Max] | 6,500 SCFH |
| Gas Type | Air |
| Gauge Size | 2 in |
| Inlet Connection | CGA 346 |
| Inlet Pressure [Max] | 3,000 psi |
| Outlet Connection | 1/4 in. NPT(F) |
| Outlet Pressure [Max] | 180 psi |
| Outlet Pressure [Min] | 0 psi |
| Type | Regulator |
| Wt. | 3 lb |
