manufacturer:
Western Enterprises
mpn:
RS-7-4
weight:
3.31
Product Description
| Lead Time | 1-2 Weeks |
|---|---|
| Manufacturer Part Number | RS-7-4 |
| GTIN | 698944045647 |
| Family | Western Enterprises RS Series Medium Duty Single Stage Regulators |
| Manufacturer | Western Enterprises |
| Manufacturer URL | http://www.westernenterprises.com |
| Hazmat | N |
| Testing and Approvals | UL Listed |
| Country of Origin | US |
| Features | 450 PSIG models have KEL-F seat to accommodate high pressure applications Dual inlet filter system extends regulator life Hydrogen and methane models equipped with pipe away relief valves Nickel chrome plated zinc bonnet |
| Body Material | Machined Brass |
| Diaphragm Material | Neoprene |
| Flow Cap. [Max] | 7,570 SCFH |
| Gas Type | Inert Gas |
| Gauge Size | 2 in |
| Inlet Connection | CGA 580 |
| Inlet Pressure [Max] | 3,000 psi |
| Outlet Connection | 9/16 in - 18 RH(M) |
| Outlet Pressure [Max] | 180 psi |
| Type | Regulator |
| Wt. | 3 lb |
