availability:
In stock
category:
Thermostats
country_of_origin:
TW
manufacturer:
White Rodgers
mpn:
1F95EZ-0671
subcategory:
Programmable
Easy Reader Thermostats offering more premium features than higher priced competitive models.
Features:
- Universal models quickly configure for single stage, multi-stage or heat pump
- Heat pump dual fuel option (with or without outdoor sensor) eliminates the need for a fossil fuel kit on selected models
- Easy Reader model is easy to read and easy to use.
- Commercial offers occupied damper or economizer control and locking cover and subbase
- Keypad lockout and set-point temperature limits
Additional Information
Voltage20 to 30 Vac 50/60 Hz
Amp Rating1.5 Amps per terminal, 2.5 Amps maximum (all terminals combined)
Set-point Range45 to 99°F (7 to 37°C)
Typical ApplicationsGas/Oil/Electric
Stages Heat/CoolUniversal - Single Stage 1H/1C, Multi-Stage 2H/2C, Heat Pump 4H/2C
StyleHorizontal
Millivolt CompatibleYes
TerminalsRC, RH, C, W/E, W2, Y, Y2, O/B, G, L, 6,
Economizer ConnectionsNo
Humidity ControlNo
Heat Pump Dual Fuel ControlYes, No Sensor Required
Heat Pump Auxiliary Lockout Control - Outdoor Sensor OptionNone
Power SourceBattery, Hardwire, Power Stealing
Auto Changeover (Heat/Cool)No
Fan OptionAuto, On
Filter Change ReminderYes
Energy Mgt. Recovery/Early StartYes
Keypad LockoutNo
Set-Point Temperature LimitsYes
Display Type6 square in.
BacklightKey Press or Continuous with Common Wire
3-Wire Zone Valve ConnectionsYes
Program OptionsProgrammable - 7 Day or Non-Programmable
Program Periods Per Day Options4, 2, None
Remote Sensor OptionsNone
