Winters Instruments - PDX8028
Features
- Heavy duty, highly accurate, aluminum case
- Brass and stainless steel wetted parts available
- Two separate bourdon tubes and pointers
- One red and one black pointer
- ASME B40.100 compliant
- CRN registered
- 5 year warranty
Applications
Comparing two separate process pressures on the same gauge|Utilized on pump and filter applications
Additional Information
Dial4.5” (115mm), 6” (150mm) white aluminum with black markings
CaseAluminum, painted black
Front FlangeSS
Back FlangeBlack steel
LensGlass
Ring4.5” (115mm): SS, 6” (150mm): Aluminum
SocketBrass or 316 SS
Connections1/4” NPT standard
ScalePSI only
Bourdon TubesPhosphor bronze or AISI 316 SS, independent, matched
MovementBrass
PointerAluminum, micrometer
WeldingTin/copper alloy for brass internals, TIG argonarc for SS internals
Over-Pressure Limit30% of full scale value
Working PressureMaximum 75% of full scale value
Ambient/Process Temperature-40°F to 150°F (-40°C to 65°C)
Accuracy±1% ANSI/ASME Grade 1A
Warning (brass internals only)This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
CategoryPressure Gauges
ManufactureWinters Instruments
MpnPDX8028
SubcategoryPdx Duplex Pressure Gauge
