Albion Engineering 875-1 Delamination Detection Tool (DDT)

Albion Engineering - 875-1

• Dramatically increase the speed and accuracy in detecting invisible delamination, voids and hollows below the surface of concrete, tile and natural stones, compared with tapping with hammers or dragging chains.
• Use for non-destructive inspections of concrete slabs, parking garages, bridge decks, beams, tile, balconies and tunnels.
• Changes in the sound of the sprocket teeth tapping the surface reveal the hidden defects.
• Safer than climbing up and down ladders with a hammer.
• Helps avoid wrist strain from repetitively tapping with a hammer.
• Also useful for non-destructive sealant adhesion testing.
• The body of the DDT Tool is a solid aluminum extrusion, threaded to accept a standard painter’s extension pole or broom handle (Albion part # 876-1 or 876-2).
• There is also a slot (with a set screw) for a marking crayon or paint pen.
• The wheels are hardened steel, mounted on precision shoulder bolt axles, spring loaded for smooth turning and maximum auditory feedback.
