category:
Piping Systems
diameter:
3
height:
3.54 "
length:
5.34 "
manufacturer:
B&K Products
mpn:
511-710
subcategory:
Union
upc:
032888361225
weight:
6.0671 lbs
width:
5.34 "
Product Description
B&K Products - 511-710 Unions do exactly what they are named to do, join two pipes to form a secure union. This fitting’s galvanization provides a layer of rust-protectant, helping to ensure a long and durable product life. General uses for this product are for transporting potable water, compressed air, drainage or creating your own DIY projects.
Features- Used for hot and cold water systems, refrigeration, sprinklers, compressed air, gasoline, diesel, alcohol, and some other applications where conducted fluid needs inner rust-proof protection
- Galvanized malleable iron construction with zinc coating
- 150-lb class malleable fittings
- This fitting works up to 500 PSI at 150°F
- Relative softness of metal helps provide a sure seal
- Threaded ends comply with ANSI/ASME B1.20.1 standards
Additional Information
Inlet Diameter (in) 3
Inlet Connection MIP
Outlet Diameter (in) 3
Outlet Connection MIP
Product Length (in) 5.34
Product Height (in) 3.54
Product Width (in) 5.34
Product Weight (lbs) 6.0671
Working Pressure (PSI) 232
Maximum Pressure (PSI) 300
Minimum Temperature (ºF) -20
Working Temperature (ºF) 77
Maximum Temperature (ºF) 347
Unit of Measure EA
Prop65 ID DEHP, Lead
Warranty Code 1-year limited warranty
Product Type Unions
Product Material Malleable Iron
Standards NSF/ANSI 372,NSF/ANSI 61,ASME B16.3,FM 1920
