Bando - 1000-KPS14M-1652 Utilizing high modulus aramid cords and the unique blue polyurethane body, the KPS II is the belt of choice for the applications requiring exceptional power transmission capabilities, particularly on lower speed-high torque drives.
- The KPS II belt transmits up to 5 times more power thana standard STS belt. This allows the same power transmission capacity to be achieved using narrower or smaller diameter pulleys, saving space and money.
- Wear-resistant polyurethane construction reduces rubber dust.
- Available in 8mm and 14 mm pitch.
- Utilize standard STS pulleys for a wide range of speed ratios.
Additional Information
Price Class551
Weight (lbs)2.3954
Number of Teeth118
Tooth Pitch (In)0.5512
Tooth Pitch (mm)14
Tooth ProfileKPS14M
Multiplier0.4844
Belt Width (In)3.937
Belt Width (mm)100
ColorBlue
Ribs/Teeth/Angle118
CordAramid
Height (In)0.3346
Height (mm)8.5
MaterialPolyurethane
Nominal Outside Length (In)65.0394
Nominal Outside Length (mm)1652
CategoryIndustrial Belts
Country of originTW
Height8.5
Length1652
ManufacturerBando
Mpn1000-KPS14M-1652
No of ribs118
SubcategoryTiming Belts
TypeSynchro-Link KPS Polyurethane (Metric)
Width100
