category:
Industrial Belts
country_of_origin:
TW
height:
0.88
length:
222
manufacturer:
Bando
mpn:
8V2220
subcategory:
V-Belts
type:
Power Ace Narrow
width:
1
Product Description
Bando - 8V2220 Power Ace® narrow profile V-belt transmits power more efficiently and effectively, delivering higher horsepower ratings than classical cross section belts. Power Ace® should be considered for any new drive application, as they can transmit the same load as classical belts in 1/2 to 2/3 the space.
- The special bias-cut angle of the cover fabric reduces stress as the belt bends around sheaves, lowering heat build-up that shortens belt life.
- Extra strong polyester cords are treated for fatigue, stretch resistance, and adhesion to assure the longest possible belt life.
- The rubber compound of the body is engineered to maintain structural uniformity while maintaining the flexibility to reduce heat build-up.
- Meets ARPM standards for oil and heat resistance and static conductivity.
Additional Information
Price Class605
Weight (lbs)7.992
Multiplier0.531
Belt Width (In)1
Belt Width (mm)25.4
ColorBlack
Ribs/Teeth/Angle0
Height (In)0.88
Height (mm)22.4
Nominal Outside Length (In)222
Nominal Outside Length (mm)5638.8
Section8V
