Block Division 04048-2-SS 4″ Swivel Eye Pulley Block 2 Sheaves for 3/8” Rope, Stainless Steel

Block Division 04048-2-SS 4″ Swivel Eye Pulley Block 2 Sheaves for 3/8” Rope, Stainless Steel

Dropship

Get it by Wed, Jan 01 - Mon, Jan 06

SKU SKU:kpi157-04048-2-SS

Regular price $176.54 USD
Regular price Sale price $176.54 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
category: Rigging & Lifting Products
country_of_origin: USA
manufacturer: Block Division
mpn: 04048-2-SS
subcategory: Pulleys
type: Swivel Eye Pulleys
weight: 5.95

Product Description

Block Division - 04048-2-SS 4″ Swivel eye pulley block, industrial quality, forged eye, double 5/8 inch machined sheave; oil impregnated bushing grooved for 3/8″ wire rope. Stainless steel finish; safe work load of 1700 lbs; weight 5.95 lbs. Options include: change the center rivet to be a removable pin/snatch; change the fastener located in the center of the pulley from a rivet to a bolt (F1); change the 2 fasteners located at the top from rivets to bolts (F2); change all 3 fasteners from rivets to bolts (F3).Dimensions in inches are approximate.

Max Cable 3/8"
Working Load 1700 LBS
A 3-1/4"
B 4"
C 5/8"
D 2-1/16"
E 1-3/16"
F 8-3/8"
G 6"
H 4-1/4"
Y 1-13/16"
Weight Each 5.95 lbs
