category:
Hydraulics & Pneumatics & Plumbing
country_of_origin:
China and Other Countries
manufacturer:
Brennan
mpn:
7005-08-S12-20-NBR
subcategory:
Fittings/Hoses/Adapters
type:
Conversion Adapters
Product Description
Brennan - 7005-08-S12-20-NBR MJ-MM STRAIGHT WITH 24 DEGREE SEAT, DIN 2353 LIGHT WITH DIN NUT AND SLEEVE ASSEMBLED
Additional Information
THREAD TYPE B1MALE JIC SAE 37 DEGREE FLARE
THREAD SIZE B13/4-16
THREAD DRILL B1 (MM)8.0
THREAD SPECIFICATION B1SAE J514
THREAD TYPE B2METRIC DIN TUBE
TUBE SIZE B2S12
THREAD SIZE B28.0
THREAD SPECIFICATION B2DIN 2353
THREAD SPECIFICATION B2ISO 8434-1
THREAD SPECIFICATION B2ASSEMBLY WITH DIN NUT & SLEEVE
DIN TUBE NUTD0318-S12
DIN TUBE SLEEVED0319-12
BODY HEX (MM)22.0
HEX C 1 (MM)24.0
OVERALL LENGTH L2 (MM)45.5
SHAPESTRAIGHT
BODY MATERIALSTEEL
RAW MATERIAL TYPESTRAIGHT STEEL
PLATINGCR3
MAXIMUM DYNAMIC PRESSURE (PSI)6,000
CALIFORNIA RESIDENTSPROP-65 WARNING
CUBIC INCH SPACE (L X W X H)1.599
ConnectionsJIC, Metric
ShapeStraight
