category:
Hydraulics & Pneumatics & Plumbing
country_of_origin:
China and Other Countries
manufacturer:
Brennan
mpn:
7005-12-S20-30-NBR-SS
subcategory:
Fittings/Hoses/Adapters
type:
Conversion Adapters
Product Description
Brennan - 7005-12-S20-30-NBR-SS MJ-MM STRAIGHT WITH 24 DEGREE SEAT, DIN 2353 LIGHT WITH DIN NUT AND SLEEVE ASSEMBLED
Additional Information
THREAD TYPE B1MALE JIC SAE 37 DEGREE FLARE
THREAD SIZE B11-1/16-12
THREAD DRILL B1 (MM)15.5
THREAD SPECIFICATION B1SAE J514
THREAD TYPE B2METRIC DIN TUBE
TUBE SIZE B2S20
THREAD SIZE B215.5
THREAD SPECIFICATION B2DIN 2353
THREAD SPECIFICATION B2ISO 8434-1
THREAD SPECIFICATION B2ASSEMBLY WITH DIN NUT & SLEEVE
DIN TUBE NUTD0318-S20-SS
DIN TUBE SLEEVED0319-20-SS
BODY HEX (MM)32.0
HEX C 1 (MM)36.0
OVERALL LENGTH L2 (MM)58.4
SHAPESTRAIGHT
BODY MATERIALSTAINLESS STEEL
RAW MATERIAL TYPESTRAIGHT STAINLESS STEEL
MAXIMUM DYNAMIC PRESSURE (PSI)5,000
CALIFORNIA RESIDENTSPROP-65 WARNING
CUBIC INCH SPACE (L X W X H)4.619
ConnectionsJIC, Metric
ShapeStraight
