category:
Electric Motors
height:
6.87
length:
8.59
manufacturer:
Century
mpn:
9222
subcategory:
AC Motors - NEMA
type:
HVAC - R Motors
weight:
14
width:
6.87
Product Overview
- OEM Direct Replacement Motor
- Unit Bearing
- Shaded Pole
- Thermally Protected
- Totally Enclosed Air Over
- Class A Insulation, 40°C Ambient
- Bearing - Unit
- 1/4 x 20 Threaded Shaft
- 35" Leads with #10 Ring Terminals
- Extended Studs Shaft End and Opposite Shaft End
Additional Information
Thermal ProtectionThermally Protected
Speed1500 rpm
Current.44 A
Number of Speeds1
Ambient Temperature40 °C
ULRecognized
Insulation ClassA
CSAY
Weight14.00 LB
Service Factor1
FrameUNIT BEARING
EnclosureTotally Enclosed Air Over
DutyContinuous
Electrical TypeShaded Pole
Poles4
RotationClockwise Lead End
Mounting2 BOSS/OSE 3 HOLES
Drive End BearingUnit
Opp Drive End BearingUnit
Frame MaterialCast Iron
Shaft TypeThreaded
Frame Length5.19 in
Shaft Diameter1/4x20 in
Shaft Extension0.4 in
Output Watts50 W
CEN
Starting MethodAcross The Line
