category:
Electric Motors
country_of_origin:
TW
height:
6.81
length:
8.81
manufacturer:
Century
mpn:
415
subcategory:
AC Motors - NEMA
type:
HVAC - R Motors
width:
6.88
Product Overview
- Furnace Blower - Attic Ventilator - Air Handler - Fan Coil Motor
- 5" Diameter - 42 Frame
- Shaded Pole
- Thermally Protected
- Open Air Over
- Class A Insulation, 40°C Ambient
- Ball Bearing
- 3/8" Diameter Shaft with Flat
- 30" Leads
- Extended Studs Opposite Shaft End, Resilient Ring Mounting
Additional Information
Thermal ProtectionAutomatic
Speed1050 rpm
Current2.5 A
Number of Speeds1
Ambient Temperature40 °C
ULRecognized
Insulation ClassA
CSAY
Weight8.00 LB
Country Of originMexico
Output HP1/12 Hp
Output KW0.06 kW
Service Factor1
Frame42
EnclosureOpen Air Over
DutyContinuous Air Over
Electrical TypeShaded Pole
Poles6
RotationClockwise Shaft End
MountingExtended Studs
Motor OrientationHorizontal
Drive End BearingBall
Opp Drive End BearingBall
Frame MaterialRolled Steel
Shaft TypeFlat
Frame Length2.92 in
Shaft Diameter0.375 in
Shaft Extension3.33 in
HTC8501.40.2040
CEN
Starting MethodAcross The Line
