Daikin

Daikin 36,000 BTU 17 SEER Dual Zone Ceiling Cassette Daikin Mini-Split Heat Pump System 12+15

Daikin 36,000 BTU 17 SEER Dual Zone Ceiling Cassette Daikin Mini-Split Heat Pump System 12+15

Dropship

SKU SKU:kpi032-4MXL36TVJUFFQ12Q2VJUFFQ15Q2VJU

Regular price $6,325.71 USD
Regular price Sale price $6,325.71 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
category: Mini Splits & Commercial Air Conditioners
manufacturer: Daikin
mpn: 4MXL36TVJUFFQ12Q2VJUFFQ15Q2VJU

Product Overview

36,000 BTU 21.7 SEER Daikin Mini-Split MXL Multi Zone Heat Pump Condenser

The Daikin Multi Zone MXL Series is the perfect fit for multi-room applications. You can connect two, three, or four indoor units to a single outdoor unit. The ability to choose from wall mount, duct units, floor mount, or ceiling cassette units offers you over 1000 combinations for your installation needs. The system also offers up to 21.7 SEER for home comfort and energy savings. The MXL Series also provides enhanced capacity performance in extreme heat and cold ambient conditions. With long-life filters and quiet operation, the MXL Series is a reliable and efficient solution for your home.With ductless mini-split systems, each room can be controlled separately using wireless or wired remotes. The MXL Series is compatible with Emura, Vista, FTXS, FVXS, FDMQ, and FDXS/CDXS indoor units, allowing you to blend them in almost invisibly with your home's existing furnishings.

Features

  • Heat Pump This system provides heating and cooling.
  • Aurora Heat Pump for extreme weather conditions
  • Outdoor Unit Quiet Operation This feature allows you to reduce the outdoor unit's sound levels by 3 dB at times when quieter operation is needed.
  • Auto-Restart This feature enables unit to memorize operation mode, airflow, and temperature settings. If there is a power failure while the unit is running, it will return to those same operating settings once the power is restored.
  • Intelligent Defrost Mode The outdoor unit can enable this mode to prevent frost and ice build up in cold climate conditions. This mode also helps deliver long hearing time for additional comfort.

Additional Information

MPN4MXL36TVJU
Refrigerant Charge precharged for: 131'
Weight (in lbs) 214.000000
AHRI Certificate Number 202522139, 202521824, 202522140
Brand/Manufacturer Daikin
Additional Information Heat Pump
Additional Information Precharged for: 131'
Additional Information Maximum Line Set Length: 98'
Additional Information Maximum System Line Set Length: 230'
Additional Information Number of Zones: 2-4
HSPF 11.2
Cooling BTU 34400
Heating BTU 36600
Decibel Level (dBA) 53-55
Energy Star Yes
Refrigerant R410A
EER 12.5
Compressor Type Swing
Liquid Line 1/4" (4)
Suction Line 3/8" (1), 1/2" (2), 5/8" (1)
Electrical 208/230v 1 Phase 60 Hz
Max Breaker Size 35 Amps
Min. Breaker Size 32.5 Amps
Tonnage 3 Ton
BTU/Tonnage 36,000 BTU/3 Ton
Min/Max Outdoor Temp for Heating -13°F - 60°F
Min/Max Outdoor Temp for Cooling 14°F - 115°F
Zone Compatibility Multi Zone
Height 34-1/4"
Width 43-5/16"
Depth 18-1/8"
Warranty 12 Years with Online Registration

12,000 BTU Ceiling Cassette Daikin Mini-Split Multi Zone Vista - Air Handler

The Daikin VISTA ceiling cassette blends design with the comfort you expect from Daikin systems. It fits within the ceiling grid and discreetly mounts into the ceiling itself, so it has a low profile. It boasts high efficiency and comfort. Additional comfort is provided by the unit's draft prevention system and individual louver control, which keeps the air from blowing directly onto your body. You can increase the efficiency by installing the optional floor and presence sensors, which adjust the temperature in a room based on whether the room is occupied or not. The sensor kit can save up to 20% in cooling and 30% in heating.Ductless mini-split heat pump systems are perfect for old and new homes or buildings, regardless of whether they have existing ductwork installed. Couple that with Daikin's beautifully designed indoor air handlers and you have elegance and efficiency that will last for years to come, guaranteed.

Features

  • Draft Reduction This feature combines a large flap and small swing flap to direct the airflow in a room. In winter, it will send warm air to the floor, and in summer, it will send cool air across the room. This produces fine air currents that circulate the air around the room.
  • Individual Louver Control You can control the delivery angle from horizontal (for cooling) or vertical (for heating). This keeps the air from blowing directly onto your body.
  • Intelligent Eye An infrared sensor detects movement in the room. When the room is occupied, the unit will operate normally. If the room is vacant for more than 20 minutes, the unit automatically switches to an energy-saving mode.

Additional Information

MPNFFQ12Q2VJU/BYFQ60C2W1W
Weight (in lbs) 36.000000
Brand/Manufacturer Daikin
Additional Information Drain: 1-1/32"
Cooling BTU 12000
Heating BTU 12000
Maximum CFM 268-427 CFM
Decibel Level (dBA) 30-39
Refrigerant R410A
Liquid Line 1/4"
Suction Line 3/8"
Electrical 208/230v 1 Phase 60 Hz
BTU/Tonnage 12,000 BTU/1 Ton
Mini-Split Type Ceiling Cassette
Zone Compatibility Multi Zone
Height 10-1/4"
Width 22-5/8"
Depth 22-5/8"
Warranty 12 Years with Online Registration

15,000 BTU Ceiling Cassette Daikin Mini-Split Multi Zone Vista - Air Handler

The Daikin VISTA ceiling cassette blends design with the comfort you expect from Daikin systems. It fits within the ceiling grid and discreetly mounts into the ceiling itself, so it has a low profile. It boasts high efficiency and comfort. Additional comfort is provided by the unit's draft prevention system and individual louver control, which keeps the air from blowing directly onto your body. You can increase the efficiency by installing the optional floor and presence sensors, which adjust the temperature in a room based on whether the room is occupied or not. The sensor kit can save up to 20% in cooling and 30% in heating.Ductless mini-split heat pump systems are perfect for old and new homes or buildings, regardless of whether they have existing ductwork installed. Couple that with Daikin's beautifully designed indoor air handlers and you have elegance and efficiency that will last for years to come, guaranteed.

Features

  • Draft Reduction This feature combines a large flap and small swing flap to direct the airflow in a room. In winter, it will send warm air to the floor, and in summer, it will send cool air across the room. This produces fine air currents that circulate the air around the room.
  • Individual Louver Control You can control the delivery angle from horizontal (for cooling) or vertical (for heating). This keeps the air from blowing directly onto your body.
  • Intelligent Eye An infrared sensor detects movement in the room. When the room is occupied, the unit will operate normally. If the room is vacant for more than 20 minutes, the unit automatically switches to an energy-saving mode.

Additional Information

MPNFFQ15Q2VJU/BYFQ60C2W1W
Weight (in lbs) 36.000000
Brand/Manufacturer Daikin
Additional Information Drain: 1-1/32"
Cooling BTU 15000
Heating BTU 15000
Maximum CFM 293-441 CFM
Decibel Level (dBA) 31-40
Refrigerant R410A
Liquid Line 1/4"
Suction Line 1/2"
Electrical 208/230v 1 Phase 60 Hz
BTU/Tonnage 15,000 BTU/1.25 Ton
Mini-Split Type Ceiling Cassette
Zone Compatibility Multi Zone
Height 10-1/4"
Width 22-5/8"
Depth 22-5/8"
Warranty 12 Years with Online Registration
