category:
HVAC Supplies
country_of_origin:
USA
depth:
9.375
height:
5.75
manufacturer:
Delta Breez
mpn:
ITG80H
subcategory:
BreezIntegrity Fans
type:
Ventilation Fan
upc:
885917002565
weight:
4.8
width:
10.75
Product Description
Delta Breez - ITG80H Delta Breez ITG80H - The Builder’s Choice for Green Construction.
Delta BreezIntegrity ITG80H is ENERGY STAR qualified with DC brushless motor engineered to run continuously for a minimum 70,000 hours; airflow rating of 80 CFM and loudness rating of 1.5 Sones at 0.1 static pressure as certified by the Home Ventilating Institute (HVI); power consumption of not more than 10.0 Watts with efficiency rating of 9.0 CFM/Watt. UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.
Features
- ENERGY STAR® qualified with DC Motor technology
- Quiet operation at 1.5 Sones
- ITG80H is UL listed for both ceiling and wall-mount installation
- Compact housing for easy retrofit and replacement of older bath fans
- Adjustable humidity set points between ~50% to ~80% RH
- Adjustable low speed for continuous operation (0 or 50 CFM options)
- UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.
- Energy efficiency at 9.0 CFM/Watts
- Annual energy cost for 24/7 operation is approximately $9.99*
ITG80H - 80 CFM Fan with Humidity Sensor
Additional Information
Fan SpeedContinuous Low Speed, Full Speed
Static Pressure (inches w.g.)0.1, 0.25, 0.1, 0.25
Air Flow (CFM)50, 36, 80, 60
Sones0.7, 1, 1.5, 1.5
Power Consumption (Watts)5, 7, 10, 12
Energy Efficiency (CFM/Watts)12, 6.9, 9, 6.2
Current (Amps)0.20 Max
Power Rating (V/Hz)120/60
