category:
ADHESIVES SEALANTS & TAPES
manufacturer:
Nasco
mpn:
230-14240
subcategory:
ADHESIVE PRODUCTS
| Manufacturer Part Number | 14240 |
|---|---|
| GTIN | 078143142406 |
| Family | Devcon 5 Minute Epoxy Gels |
| Manufacturer | Devcon |
| Manufacturer URL | http://www.devcon.com |
| Hazmat | N |
| Testing and Approvals | Chemical resistance was tested by immersion for 30 days at 75 F, after 7 days room temperature cure; Cured hardness tested according to ASTM D-2240; Cured density tested according to ASTM D1002; Compression strength tested according to ASTM D695; Dielectric strength tested according to ASTM D149 |
| Country of Origin | US |
| Features | Thixotropic, nonmigrating gel adhesive with excellent gap filling properties High tensile strength Good solvent resistance Non-sagging adhesive Fills gaps to .25 inch Fast curing for bond tags on machinery and equipment |
| Adhesive Tensile Shear | 2,500 psi |
| Applicable Materials | Wood; Most Metals; Ceramic; Fabric; Concrete; Steel; Aluminum; Copper; Ferrites |
| Applications | Multi-Purpose |
| Capacity Vol. [Nom] | 25 mL |
| Chemical Compound | Epoxy |
| Color | Opaque |
| Dielectric Strength | 440 V/mil |
| Fix Cure Time @ Temp. | 1 h @ 75 F |
| Full Cure Time @ Temp. | 16 h @ 75 F |
| Gap Fill [Nom] | 1/4 in |
| Hardness [Nom] | 80 Shore D |
| Packing Type | Dual Syringe Tube |
| Resistance | Kerosene; Sulfuric Acid-10%; Toluene; Hydrochloric Acid 3% |
| Temp. Range [Max] | 200 F |
| Temp. Range [Min] | -40 F |
| Viscosity [Nom] | 150,000 cP |
| Working Time [Max] | 7 min |
| Working Time [Min] | 4 min |
| Working Time [Nom] | 4-7 min |
| Wt. | 0.15 lb |
