category:
Electric Motors
height:
3.38
length:
11
manufacturer:
Century
mpn:
D1107
subcategory:
AC Motors - NEMA
type:
HVAC - R Motors
weight:
5
width:
3.38
Product Overview
- OEM Direct Replacement Motor
- 3.3" Diameter
- Shaded Pole
- Thermally Protected
- Open Air Over
- Class B Insulation, 40°C Ambient
- Ball Bearing
- 5/16" Diameter Shaft with Flat
- 25" Leads
- Belly Band Mount (Belly Band Not Included)
Additional Information
Thermal ProtectionThermally Protected
Speed1550 rpm
Current3.20 A
Number of Speeds1
Ambient Temperature40 °C
ULRecognized
Insulation ClassB
CSAY
Weight5.00 LB
Country Of originMexico
Output HP1/10 Hp
Output KW0.07 kW
Frame3.3
EnclosureOpen Air Over
DutyAir Over
Electrical TypeShaded Pole
Poles4
RotationCounterclockwise Shaft End
MountingRound Belly Band
Drive End BearingBall
Opp Drive End BearingBall
Frame MaterialSteel
Shaft TypeFlat
Frame Length3.70 in
Shaft Diameter0.312 in
Shaft Extension1.45 in
CEN
Starting MethodAcross The Line
