category:
Full Product Range
height:
18.11
length:
26.77
manufacturer:
Fein
mpn:
71700261090
subcategory:
Magnetic Base Drilling
width:
9.45
Product Description
Fein - 71700261090
- Extremely wear-resistant tool concept with swivel-mounted motor cable protection hose for tough conditions in industry and skilled trades.
- Small and lightweight tool for persistently high long-term work progress thanks to brushless FEIN PowerDrive motor with tacho electronics and FEIN HighPower battery with high-current-capable cells.
- Flexibility in all mobile drilling operations, such as mag base drilling, spiral drilling, tapping, sinking and reaming.
- FEIN HighPower Li-ion battery. Continuously high current output with 75% higher amperage than Li-ion batteries for high cutting speed.
- Simple and error-proof control concept in the operator's field of view.
- Convenient magnetic holding force display.
- Motion sensor.
- Reversible.
- Electronic speed control.
- Extra long stroke.
- MT2 tool mounting.
- Extra narrow permanent magnet with magnetic bias.
- "Memory function" speed storage.
- The battery capacity can be read directly on the battery.
- FEIN SafetyCell technology. Protects the battery and the machine from overloading, overheating and deep discharge.
- optional using accessory.
- Highest performance with FEIN HighPower Li-ion battery.
Additional Information
Battery voltage18 V
Battery compatibilityLi-ion / HighPower Li-ions**
Battery interface18 V
Weight without battery26.68 [12.10] lbs[kg]
Battery capacity5.2 Ah
Full load speed130 - 520 rpm
Weight incl. battery28.22 [12.80] lbs[kg]
Sound pressure level LpA82,4 dB
Sound power level LWA93,4 dB
Peak sound value LpCpeak97,1 dB
Vibration value 1 ahv 3-wayah,D 0,6 m/s²
Motorbrushless
Tool mountMT 2
TappingM 14
Carbide cutter max. dia.1-3/8 [35] in[mm]
HSS cutter max. dia.1-3/8 [35] in[mm]
Cutter max. drilling depth2 [50] (3 [75] )* in[mm]
Twist drill max. dia.3/4 [18] in[mm]
Max. countersinking dia.1-1/4 [31] in[mm]
Reaming max. dia.3/4 [18] in[mm]
Cutter holder3/4" Weldon
Cutter changetool-free
Stroke5-5/16 [135] in[mm]
Total stroke range10-1/4 [260] in[mm]
Magnetic holding force2023 [9,000] lbs[N]
Magnetic base dimensions7-11/16 [195] x 2-3/4 [70] in[mm]
