Century

Genteq HEAT SHIELD® Condenser Fan Motor, 3/4 HP, 1 Ph, 60 Hz, 208-230 V, 1075 RPM, 1 Speed, 48 Frame, TEAO - 3731HS

Genteq HEAT SHIELD® Condenser Fan Motor, 3/4 HP, 1 Ph, 60 Hz, 208-230 V, 1075 RPM, 1 Speed, 48 Frame, TEAO - 3731HS

Dropship

SKU SKU:kpi045-3731HS

Regular price $181.25 USD
Regular price Sale price $181.25 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
category: Electric Motors
height: 6.02
length: 15.49
manufacturer: Century
mpn: 3731HS
subcategory: AC Motors - NEMA
type: HVAC - R Motors
weight: 21
width: 6.04

Product Overview

  • Heat Shield - Condenser Fan Motor
  • 5.6" Diameter - 48 Frame
  • Permanent Split Capacitor (PSC); Capacitor Required: 15 Mfd-370 Volts (Not Supplied with Motor)
  • Thermally Protected
  • Totally Enclosed Air Over
  • Class B Insulation, 70°C Ambient
  • Sleeve Bearing
  • 1/2" Diameter Shaft with Double Flat
  • 48" Leads
  • Extended Clampbolts, Mounting Holes in shell, Belly Band Mount (Belly Band Not Included)

Additional Information

Thermal ProtectionThermally Protected
Speed1075 rpm
Current4.10 A
Number of Speeds1
Ambient Temperature70 °C
ULRecognized
Insulation ClassB
CSAY
Weight21.00 LB
Country Of originMexico
Output HP3/4 Hp
Output KW0.56 kW
Service Factor1
Frame48
EnclosureTotally Enclosed Air Over
DutyContinuous Air Over
Electrical TypePermanent Split Capacitor
Poles6
RotationReversible
MountingRound Belly Band
Motor OrientationAny
Drive End BearingSleeve
Opp Drive End BearingSleeve
Frame MaterialRolled Steel
Shaft TypeDouble Flat
Frame Length5.57 in
Shaft Diameter0.500 in
Shaft Extension6.50 in
CEN
