Goodman

Goodman 5 Ton 15.2 SEER2 80% AFUE 100,000 BTU Goodman Communicating Gas Furnace and AC+ Heat System - Upflow

Goodman 5 Ton 15.2 SEER2 80% AFUE 100,000 BTU Goodman Communicating Gas Furnace and AC+ Heat System - Upflow

Dropship

SKU SKU:kpi027-GSZC706010CAPT4961C4GMVC801005CN

Regular price $8,106.00 USD
Regular price Sale price $8,106.00 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
capacity: 60000 BTU
category: Furnaces
furnace_efficiency_afue: 80%
heating_capacity: 60000 BTU
manufacturer: Goodman
mpn: GSZC706010CAPT4961C4GMVC801005CN
subcategory: AC Units,Furnaces & Heat Pumps
type: AC Units
weight: 512

Goodman - GSZC706010CAPT4961C4GMVC801005CN Considered part of the highest quality series offered by Goodman, the GSZC706010 heat pump condenser is a superior to any other series made by Goodman. With all of its features, the GSZC706010 continues to promote Goodman's goals to provide enhanced comfort at a high efficiency while staying under budget.

Features
  • Designed to cover a larger house in average climates
  • 5 ton, 17 SEER2 heat pump condenser
  • Two stage compressor
  • Low sound output
  • Fully charged for up to 15 ft of line set
  • Factory installed bi-flow filter drier

Additional Information

MPNGSZC706010
Weight (in lbs) 315.000000
Brand/Manufacturer Goodman
Replaces GSZC160601, GSZC180601
HSPF 8.2
Cooling BTU 60,000
Heating BTU 60,000
Decibel Level (dBA) 78
Horsepower .33
Energy Star Yes
Refrigerant R410A
SEER2 (Efficiency) 17
Condenser Stages Two Stage
Compressor Type Scroll
Liquid Line 3/8"
Suction Line 1 1/8"
Liquid Valve Size 3/8"
Suction Valve Size 7/8"
Electrical 208/230 V 1 Phase 60 Hz
Max Breaker Size 50
Amperage Requirement 32.4
Tonnage 5 Ton
Height 41 5/8"
Width 35 1/2"
Depth 35 1/2"
Warranty Lifetime compressor, 10 year unit replacement, and 10 year parts limited warranties

4 to 5 Ton 21" Width Goodman Cased Evaporator Coil with TXV

The Goodman CAPT4961C4 evaporator coil is ready for any vertical installation that you need it for. With a built-in TXV kit for efficiency, the CAPT4961C4 lives up to Goodman™s expectations to provide an enhanced comfort with a superior efficiency, all while staying within your budget. If you want the best possible coil for your home, this is it.

Features
  • 4 to 5 ton vertical evaporator coil
  • Installable in the upflow or downflow configuration
  • Usable with either a heat pump or an AC-only condenser
  • Low air leakage
  • Factory-installed TXV

Additional Information

MPNCAPT4961C4
Weight (in lbs) 73.000000
Brand/Manufacturer Goodman
Configuration Upflow / Downflow
Liquid Line 3/8"
Suction Line 7/8"
Tonnage 4 Ton to 5 Ton
Style A-Coil
Height 30"
Width 21"
Depth 21"
Warranty 10 Years with Online Registration

100,000 BTU 80% AFUE Variable Speed Goodman Gas Furnace - Upflow/Horizontal

The GMVC801005CN gas furnace is from one of the top-of-the-line series by Goodman. Considered one of the best of the best, this furnace has a two stage burner and a variable speed blower motor. With the best durability and reliability that Goodman 80% efficient furnaces have to offer, we are proud to offer you the Goodman GMVC801005CN gas furnace.

Features
  • This furnace is ideal to heat a medium-sized house (in average climate conditions)
  • 100,000 BTU 80% AFUE two stage variable speed natural gas furnace
  • Requires metal flue venting
  • Can be used in the upflow or horizontal orientation
  • Can be converted to propane with an LP conversion kit (sold separately)
  • Innovative design for electrical efficiency, safety, and lower sound output

Additional Information

MPNGMVC801005CN
Weight (in lbs) 124.000000
Exhaust Flue Requirement Metal
Brand/Manufacturer Goodman
Furnace Efficiency / AFUE 80%
Heating BTU 100,000
Blower Motor Variable Speed
Maximum CFM 2200
Configuration Upflow/Horizontal
Electrical 120 V. 1 Phase 60 Hz
Burner Stages Two
Fuel Type Propane, Natural Gas
Height 33.4"
Width 21"
Depth 28"
Warranty 10 Years with Online Registration
