Goodman

Goodman 5 Ton 15.2 SEER2 96% AFUE 120,000 BTU Goodman Communicating Gas Furnace and AC+ Heat System - Horizontal (GSZC-CHPT-GMVC)

Goodman 5 Ton 15.2 SEER2 96% AFUE 120,000 BTU Goodman Communicating Gas Furnace and AC+ Heat System - Horizontal (GSZC-CHPT-GMVC)

Dropship

SKU SKU:kpi027-GSZC706010CHPT4860D4GMVC961205DN

Regular price $8,793.00 USD
Regular price Sale price $8,793.00 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
capacity: 60000 BTU
category: Furnaces
furnace_efficiency_afue: 96%
heating_capacity: 60000 BTU
manufacturer: Goodman
mpn: GSZC706010CHPT4860D4GMVC961205DN
subcategory: AC Units,Furnaces & Heat Pumps
type: AC Units
weight: 552

Goodman - GSZC706010CHPT4860D4GMVC961205DN Considered part of the highest quality series offered by Goodman, the GSZC706010 heat pump condenser is a superior to any other series made by Goodman. With all of its features, the GSZC706010 continues to promote Goodman's goals to provide enhanced comfort at a high efficiency while staying under budget.

Features
  • Designed to cover a larger house in average climates
  • 5 ton, 17 SEER2 heat pump condenser
  • Two stage compressor
  • Low sound output
  • Fully charged for up to 15 ft of line set
  • Factory installed bi-flow filter drier

Additional Information

MPNGSZC706010
Weight (in lbs) 315.000000
Brand/Manufacturer Goodman
Replaces GSZC160601, GSZC180601
HSPF 8.2
Cooling BTU 60,000
Heating BTU 60,000
Decibel Level (dBA) 78
Horsepower .33
Energy Star Yes
Refrigerant R410A
SEER2 (Efficiency) 17
Condenser Stages Two Stage
Compressor Type Scroll
Liquid Line 3/8"
Suction Line 1 1/8"
Liquid Valve Size 3/8"
Suction Valve Size 7/8"
Electrical 208/230 V 1 Phase 60 Hz
Max Breaker Size 50
Amperage Requirement 32.4
Tonnage 5 Ton
Height 41 5/8"
Width 35 1/2"
Depth 35 1/2"
Warranty Lifetime compressor, 10 year unit replacement, and 10 year parts limited warranties

3.5 to 5 Ton 24.5" Height Goodman Horizontal Evaporator Coil - Cased

The Goodman CHPT4860D4 evaporator coil is ready for any horizontal installation that you need it for. With a built-in TXV kit for efficiency, the CHPT4860D4 lives up to Goodman's expectations to provide an enhanced comfort with a superior efficiency, all while staying within your budget. If you want the best possible coil for your home, this is it.

Features
  • 3.5 to 5 ton horizontal evaporator coil
  • Can be used with heat pump and AC-only condensers
  • Galvanized, embossed, and insulated coil cabinet to protect the coil and prevent air leakage
  • Factory-installed TXV kit

Additional Information

MPNCHPT4860D4
Weight (in lbs) 81.000000
Brand/Manufacturer Goodman
Configuration Horizontal
Refrigerant R410A
Liquid Line 3/8"
Suction Line 7/8"
Tonnage 5 Ton
Style A-Coil
Certification ETL Listed
Height 24.5"
Width 26"
Depth 21 1/8"
Warranty 10 Years Parts with Online Registration

120,000 BTU 96% AFUE Variable Speed Goodman Gas Furnace - Upflow/Horizontal

With top of the line technology at high efficiency, two stage burner, and variable speed blower motor, the GMVC961205DN gas furnace is another masterpiece by Goodman. With enhanced durability and reliability, you can expect this Goodman gas furnace to perform well throughout its entire life and keep money in your pocket.

Features
  • This furnace is ideal to heat a larger house (in average climate conditions)
  • 120,000 BTU 96% AFUE two stage variable speed natural gas furnace
  • Requires plastic/PVC flue venting
  • Can be used in the upflow or horizontal orientation
  • Can be converted to propane with an LP conversion kit (sold separately)
  • Innovative design for electrical efficiency, safety, and lower sound output

Additional Information

MPNGMVC961205DN
Weight (in lbs) 156.000000
Exhaust Flue Requirement Plastic / PVC
Brand/Manufacturer Goodman
Furnace Efficiency / AFUE 96%
Heating BTU 120,000
Blower Motor Variable Speed - ECM
Maximum CFM 2000
Configuration Upflow/Horizontal
Exhaust Pipe PVC
Flue Location Right
Energy Star Yes
Electrical 115 V. 1 Phase 60 Hz
Burner Stages Two
Fuel Type Propane, Natural Gas
Height 34.5"
Width 24.5"
Depth 28.75"
Warranty 10 Years with Online Registration
