Goodman 5 Ton 15.2 SEER2 97% AFUE 120,000 BTU Goodman Communicating Gas Furnace and AC+ Heat System - Upflow

Goodman 5 Ton 15.2 SEER2 97% AFUE 120,000 BTU Goodman Communicating Gas Furnace and AC+ Heat System - Upflow

Dropship

Get it by Sat, Dec 14 - Thu, Dec 19

SKU SKU:kpi027-GSZC706010CAPT4961D4GMVM971205DN

Regular price $9,307.00 USD
Regular price Sale price $9,307.00 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
capacity: 60000 BTU
category: Furnaces
furnace_efficiency_afue: 97%
heating_capacity: 60000 BTU
manufacturer: Goodman
mpn: GSZC706010CAPT4961D4GMVM971205DN
subcategory: AC Units,Furnaces & Heat Pumps
type: AC Units
weight: 534

Product Description

Goodman - GSZC706010CAPT4961D4GMVM971205DN Considered part of the highest quality series offered by Goodman, the GSZC706010 heat pump condenser is a superior to any other series made by Goodman. With all of its features, the GSZC706010 continues to promote Goodman's goals to provide enhanced comfort at a high efficiency while staying under budget.

Features
  • Designed to cover a larger house in average climates
  • 5 ton, 17 SEER2 heat pump condenser
  • Two stage compressor
  • Low sound output
  • Fully charged for up to 15 ft of line set
  • Factory installed bi-flow filter drier

Additional Information

MPNGSZC706010
Weight (in lbs) 315.000000
Brand/Manufacturer Goodman
Replaces GSZC160601, GSZC180601
HSPF 8.2
Cooling BTU 60,000
Heating BTU 60,000
Decibel Level (dBA) 78
Horsepower .33
Energy Star Yes
Refrigerant R410A
SEER2 (Efficiency) 17
Condenser Stages Two Stage
Compressor Type Scroll
Liquid Line 3/8"
Suction Line 1 1/8"
Liquid Valve Size 3/8"
Suction Valve Size 7/8"
Electrical 208/230 V 1 Phase 60 Hz
Max Breaker Size 50
Amperage Requirement 32.4
Tonnage 5 Ton
Height 41 5/8"
Width 35 1/2"
Depth 35 1/2"
Warranty Lifetime compressor, 10 year unit replacement, and 10 year parts limited warranties

4 to 5 Ton 21" Width Goodman Cased Evaporator Coil with TXV

The Goodman CAPT4961C4 evaporator coil is ready for any vertical installation that you need it for. With a built-in TXV kit for efficiency, the CAPT4961C4 lives up to Goodman™s expectations to provide an enhanced comfort with a superior efficiency, all while staying within your budget. If you want the best possible coil for your home, this is it.

Features
  • 4 to 5 ton vertical evaporator coil
  • Installable in the upflow or downflow configuration
  • Usable with either a heat pump or an AC-only condenser
  • Low air leakage
  • Factory-installed TXV

Additional Information

MPNCAPT4961D4
Weight (in lbs) 76.000000
Brand/Manufacturer Goodman
Configuration Upflow / Downflow
Liquid Line 3/8"
Suction Line 7/8"
Tonnage 4 Ton to 5 Ton
Style A-Coil
Height 30"
Width 24.5"
Depth 21"
Warranty 10 Years with Online Registration

120,000 BTU 97% AFUE Upflow Variable Speed Goodman Gas Furnace

With a variable speed blower motor and modulating gas valves, the GMVM971205DN is from the best furnace series that Goodman has to offer. At 97% efficiency, this furnace has the highest possible efficiency available in today™s technology and offered by Goodman. If you want the best of the best for your home, the GMVM971205DN is the furnace for you.

Features
  • Ideal to heat a larger house (in an ideal climate)
  • 120,000 BTU 97% AFUE modulating variable speed natural gas furnace
  • Requires plastic/PVC flue venting
  • Can be installed in the upflow or horizontal orientation
  • Can be converted to propane with an LP conversion kit (sold separately)
  • Innovative design for electrical efficiency, safety, and lower sound output

Additional Information

MPNGMVM971205DN
Weight (in lbs) 146.000000
Exhaust Flue Requirement Plastic / PVC
Brand/Manufacturer Goodman
Furnace Efficiency / AFUE 97%
Heating BTU 120,000
Blower Motor Variable Speed - ECM
Maximum CFM 2000
Configuration Upflow/Horizontal
Exhaust Pipe PVC
Flue Location Right
Energy Star Yes
Electrical 115 V. 1 Phase 60 Hz
Burner Stages Modulating
Fuel Type Propane, Natural Gas
Height 34.5"
Width 24.5"
Depth 28.75"
Warranty 10 Years with Online Registration
