ICM Controls ICM256C Post Purge Fan Timer 18 to 30V

Fan Blower Control - Dual On/Off Delay Timer (Fixed Time Delay) w/ Post Purge Dual function fan delay timer Controls the circulating fan in forced air systems Off delay purges duct of residual air On delay allows air to reach proper comfort level prior to energizing the fan

• Dual function fan delay timer
• Controls the circulating fan in forced air systems
• Off delay purges duct of residual air
• On delay allows air to reach proper comfort level prior to energizing the fan

• Weight: 1

Input:
-Voltage: 18-30 VAC
-Frequency: 50/60 Hz

Output:
-N.O.: 25 amps @ 240 VAC

Fixed Time Delays:
-On: 7 seconds
-Off: 65 seconds
