Innovair WIN24H2V51 Quantum Heat Pump Single Zone Mini Split System (24000 BTU)

Innovair WIN24H2V51 Quantum Heat Pump Single Zone Mini Split System (24000 BTU)

Dropship

SKU SKU:kpi038-WIN24H2V51

Regular price $1,220.00 USD
Regular price Sale price $1,220.00 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
capacity: 24000 BTU
category: Complete AC System
class: Single Zone Mini Split System
depth: 12
height: 25
manufacturer: Innovair
mpn: WIN24H2V51
seer: 17.6
subcategory: Single Zone Mini Split Systems
volts: 208~230V / 60Hz / 1phase
weight: 143
width: 34

Product Description

Innovair - WIN24H2V51

Catechin filter remove odors and remove dust and particles from the air and room.The HEPA filter helps eliminate pollen, mill dust, and bacteria, bringing fresh and healthy air to you.Emits Vitamin C through the air to everyone for healthier skin.Silver Ion filter sterilizes bacteria effectively by destroying their inner configuration.Heating belt is fitted on the base plate of the outdoor unit to prevent water accumulation, which improves heat transfer efficiency.

Unlike traditional compressors that turn on and off multiple times, Innovair inverter compressors feature variable power that automatically adjusts the running speed to maintain the desired temperature. That way, an Innovair unit runs quietly and features significant energy savings.The Innovair Mini split can cool down an indoor space to a desired, comfortable indoor temperature, even when outside temperatures reach up to 122°F.

Innovair Mini splits can be a primary heating source with its ability to operate at cold outdoor temperatures. Stay warm inside while its cold outside.One click to limit the maximum frequency current while still maintain the room temperature within the optimal temperature, guarantee a cool night sleep with maximum energy saving.With this function, the air conditioner will maximize the output of cooling capacity, making the room cool down rapidly, and attain the desired temperature in the shortest time.

Features:

-
  • Remote control has a sensor built-in for a more accurate reading
  • Inverter Technology delivering up to 17.6 SEER Rated Efficiency
  • Directional air-outlet moves automatically both horizontal and vertical
  • AHRI Certified Units
  • Clear coated control boards to protect against corrosion
  • Dry mode allows to remove excess humidity without changing the temperature
  • More resistant to oxidation and corrosion than ordinary blue fin
  • Can operate as a Heat Pump or Cooling System
  • Able to maintain cooling operation with outdoor temperatures as high as 129°F
  • To protect your system's air quality from unwanted dust
  • Ability to operate as with outdoor temperatures low as -4°F
  • Minimal disassembly for quicker maintenance
  • Lower dB(A) than conventional units
  • Eco Friendly refrigerant for a cleaner environment
  • Operations will self adjust while operating at low sound levels
  • Quickly cools down at higher fan speeds to reach set temperature
  • Stable operations with wide voltage range

Additional Information

ModelWIN24H2V51
Capacity-Btu/H24000
Electrical-Volt / Hertz208~230V / 60Hz11.0
Electrical-Minimum Circuit (A)11
Cooling-Capacity Range (Btu/H)6,500 ~ 24,200
Cooling-Rated Current (A)10.5
Cooling-Seer17.6
Heating-Capacity Range (Btu/H)6,500 ~ 24,500
Heating-Rated Current (A)10.4
Heating-Hspf9.8
Oper. Ambient Temp.-Cooling (°F )5 °F ~ 115 °F
Oper. Ambient Temp.-Heating (°F )4 °F ~ 75 °F
Circuit Breaker Size-(A)30
Moisture Removal-Liter/Hr2.4
Refrigerant-R410A (Oz)57.5
Refrigerant-Additional Refrigerant (Oz/Ft)0.32
Refrigerant Connections-Liquid (In)3/8"
Refrigerant Connections-Suction (In)5/8"
Refrigerant Connections-Pre-Charged Length (Ft)25
Refrigerant Connections-Maximum Length (Ft)66
Refrigerant Connections-Maximum Height (Ft)33
Air Flow-CFM405 ~ 775
Sound Level-DB(A) Indoor Unit32 ~ 42
Control-Remote ControlLCD WIRELES REMOTE CONTROL or WIFI (optional)
Control-Auto RestartYES
Control-ProtectionTime Delay
Dimensions Indoor Unit-W X H X D (In)42 ¾ x 12 ½ x 9 ¾
Weight Indoor Unit-Net33 Lbs
Compressor-RLA12.0
Sound Level-DB(A) Outdoor Unit58
Dimensions Outdoor Unit-W X H X D (In)34 x 25 ¾ x 12 ¼
Weight Outdoor Unit-Net110 Lbs
