Product Description
Levtech - LSP-TCT-WIFI Our advanced conductivity and temperature transmitter is specifically designed for water treatment applications that require precise conductivity measurement along with temperature compensation. The device is equipped with a built-in web server, allowing easy access via a wifi connection. Simply open the device menu in your web browser on your phone or laptop to configure the parameters according to your specific needs.The output of the device can be configured to 0-10V or 4-20mA analog signals and it also supports MODBUS connection. This transmitter can be connected to any type of resistive conductivity sensor.
The LSP-TCT-WIFI conductivity and temperature transmitter is designed to measure the conductivity, resistivity and temperature of the liquids with the corresponding sensor. This instrument is suitable for high-purity water monitoring and other water treatment applications, such as reverse osmosis or ion exchangers. With its DIN rail mountable housing, it is easy to install into industrial environments. Configuration of the parameters can be easily done by accessing the device’s built-in web-server through its WiFi connection.
Features- Convenient Wi-Fi connection for streamlined configuration
- MODBUS protocol
- Precise conductivity, resistivity, and temperature measurements
- Adjustable signal outputs for both conductivity and temperature (0 -20mA; 4-20mA; 0-24mA; 0-10V)
- Digital output Relay with a customizable switching point
- Automated self-calibration for optimal accuracy
- Linear temperature compensation
- Electric isolation of input, output, and power supply
- DIN rail mounting for flexible installation
- Resisitivity compensation of the cable
- Cell constant calibration
