Lufkin LSSP4NE EX4 NITE EYE™ Extendable Trim Square

Product Description

Crescent's NITE EYE™ EX4 Extendable Square combines the benefits of a 4" trim square and 7" rafter square. Its permanent, high visibility markings will hold up on the jobsite. The aluminum frame is lightweight and corrosion resistant. The square offers both a bottom heel ruler and scribe notches down to 1/8th of an inch for accurate measurements from any angle. The heel also features a dual reference with a 1/4" and 3/8" offset for quick measurements. This compact square provides all the features needed for trim work while also being able to expand for bigger cuts.

• Black square with high-contrast markings improves legibility in all light conditions
• Patented fold out extension creates a 2-in-1 rafter/trim square eliminating the need to carry a 4" and 7" square.
• Fold out extension acts as a continuous edge for scribing and marking various timber and trim
• 1/4" and 3/8" dual reference heel measurements for quick marks, and centering mortises and tenons
• Full-length ruler along the bottom heel for measuring heights and from unusual angles
• Scribe notches every 1/4" and 1/8" for increased marking capabilities
• Markings at 22.5 degrees, 30 degrees, 45 degrees and 67.5 degrees for fast angle measurements

• Weight (Catalog): 0.500 lb
• Warranty: Full Lifetime
• Type: Extendable Square
• NITE EYE™: Yes
• Family Name: Nite Eye™
• Overall Length: 5.25 in
• Size: 5-1/4" edge, 4-1/8" heel and 6-3/4" angle edge
• Overall Width: 4.25 in
• Magnetic: No
• Overall Height: 0.92 in
• UPC: 037103381002
• Prop 65: WARNING: This product contains or produces a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
• Material: Aluminum
• Graduation: 1/8th Inches
• Color: Black
• Measuring Range: 0 in - 4 in
• Tether Ready: No
• Measurement Type: SAE
• Packaging: Carded
