category:
Water Feeders
manufacturer:
McDonnell & Miller
mpn:
134300
weight:
11.0
Product Overview
Features- For receiver tanks in commercial or industrial applications
- Mounts directly on the receiver, eliminating need for equalizing connections
- Quick-change replaceable cartridge valve and strainer
- Proportional feed action
- Mounting Flange – six 7/16" (11.1mm) bolt holes on a 53/4" (146mm) bolt circle
- Maximum supply pressure 150 psi (10.5 kg/cm2)
- Maximum inlet water temperature 120 Deg. F (49 Deg. C)
- Maximum receiver pressure 25 psi (1.8 kg/cm2)
Additional Information
ApplicationBoiler Receiver Tanks
TypeMake-Up
Max Pressure (PSI)150
Max Vessel Pressure25 psi
Max Inlet Water Temp (F)120°F
Width (Inches)12-1/4"
Mount5-3/4" Bolt Circle
Size1/2"
Connection TypeThreaded
