MRCOOL

MRCOOL 24k BTU 20.5 SEER DIY Series Ductless Wall Mounted and Heat Pump Split System 4th Generation

MRCOOL 24k BTU 20.5 SEER DIY Series Ductless Wall Mounted and Heat Pump Split System 4th Generation

Dropship

Get it by Tue, Dec 24 - Sun, Dec 29

SKU SKU:kpi035-DIY-24-HP-WM-230C25

Regular price $2,502.00 USD
Regular price Sale price $2,502.00 USD
Sale Sold out
Shipping calculated at checkout.
View full details
  • 30-day returns
  • Fast shipping
  • Secure payments
  • Over 300,000 products
capacity: 24000 BTU (2 Ton)
category: Combo Sets
manufacturer: MRCOOL
mpn: DIY-24-HP-WM-230C25
product_color: White
seer: 20.5
series: DIY 4th Gen E STAR
subcategory: DIY 4th Gen. Ductless AC Unit
voltage: 208-230 V
weight: 185

Product Description

MRCOOL - DIY-24-HP-WM-230C25

The 4th Generation MrCool DIY 24k BTU 20.5 SEER Ductless Heat Pump Mini Split System's pre-charged Quick Connect line set allows you to effortlessly install the system in your home without any extra tools, training, or equipment. No need for a vacuum as the lines are already pre-charged with R-410A refrigerant which is more environmentally friendly than older refrigerants.

The DIYPRO cable makes installation of the 4th Generation MrCool DIY 24k BTU 20.5 SEER Ductless Heat Pump Mini Split System even easier. The unique cable allows you to install the system without any electrical conduit. The cable, with easy crimp connectors, protects against weather, animals, and yardwork tools. Using the cable will ensure protection of the mechanical features and create durability.

The many modes and functions of the MrCool DIY Ductless Mini Split will give you a variety of options to keep your home comfortable. These include an auto mode that allows you to set the unit temperature and allow it to maintain your most comfortable environment without additional adjustment on your part. The timer function will allow you to limit your energy consumption by shutting off when heating and cooling isn't needed. Also, if a power outage occurs, the unit will automatically restart and will proceed to heating or cooling your space to your previous settings immediately.

This Bundle Includes :

24k BTU 20.5 SEER MrCool DIY Ductless Heat Pump Condenser - 4th Generation - with 25 ft Line Set

24k BTU MrCool DIY Ductless Wall Mounted Air Handler - 4th Generation 240v

Additional Information

Model DIY-24-HP-C-230C25
AHRI Number 207339189
UPC 810063868529
Avg Coverage Area 1,000 - 1,500 Sq Ft
Compressor Inverter
Cooling Capacity 2 Ton
Electrical Phase 1-Phase
Heat Pump Efficiency (HSPF) 10.5
Line Set Connection Type Quick Connect
Liquid Line Size 3/8 inch
Max Overcurrent Protection 35 amps
Primary Heating Capacity 20,001 - 25,000 BTU
Product Height (in) 31.89
Product Length (in) 16.14
Product Width (in) 37.24
Refrigerant R-410a
Cooling Efficiency 19 SEER and Above
Series DIY
Suction Line Size 5/8 inch
System Application Type Ductless Split Systems
Voltage 240
Weight(lbs)125

Additional Information

Model DIY-24-HP-WMAH-230C25
UPC 810063868536
Air Flow Direction Horizontal
Configuration Wall Mounted
Blower Motor Variable Speed
Cooling Capacity 2 Ton
Electrical Phase 1-Phase
Line Set Connection Type Quick Connect
Liquid Line Size 3/8 inch
Max Overcurrent Protection 15 amps
Product Height (in) 13.19
Product Length (in) 8.9
Product Width (in) 42.52
Refrigerant R-410a
Series DIY
Suction Line Size 5/8 inch
System Application Type Ductless Split Systems
Voltage 240
Warranty 5 Year Parts
Weight (lbs) 60.19
