Product Description
MRCOOL - MHP15060A 5 Ton 60,000 BTU Split System Heat Pump
The MRCOOL 15 SEER Heat Pump Split System works diligently to make your home a comfortable space. This product gives you total energy efficiency with it's enhanced tube-and-fin coil design, allowing you to get more bang for your buck. You can have peace-of-mind with this product due to its affordability, quality, efficiency, and comfort. Look no further for your family's next home central heating and air system.
Features:
- Louvered construction with baked polyester finish over galvanized steel to withstand bad weather
- Raised coil to prevent debris blockage
- CoolGuard advanced corrosion resistant coil
- 4-screw louver panels, corner-mounted controlsand 45-degree offset valves for easy service.
- Enhanced tube-and-fin coil design featuring high efficiency heat transfer technology
- Thread-on pressure switches for simple, quick replacement
- Charged for 15 feet of line set
- Heavy-duty compressor sound blanket forquiet operation
- Internally protected against high temperature motor overload conditions
- Ships with filter drier
- All units ETL and ETLC approved and AHRI Certified
Additional Information
Series_Extmhp15
Unit_TypeSplit System Heat Pump
Net_Depth32.25 in
Net_Height43 in
Net_Width32.25 in
Net_Weight297
Seer15
Max_Seer14-15
Eer12
Cop_473.5
Cop_47_Part_Load2.6
Hspf8.2-8.5
Cfm1900-1930
Tonnage5
Cooling_Capacity57000
Heating_Capacity55000
Voltage208-230
Phase1
Cycle60
StageSingle
Max_Fuse_Breaker50
Min_Circuit_Ampacity29.4
ColorGray
Color_FamilyGray
Rated_Load22.1
Max_Coverage_Area2500
Refrigerant_TypeR-410A
Refrigerant_Volume197
Decibel_Rating80
InverterNo
Min_Ambient_Cool55
Lineset_IncludedNo
Line_Set_Length15ft, 25ft, 35ft, 50ft
Max_Lineset_Length50ft
Lineset_Fitting_TypeSweat
Liquid_Line_Size3/8 in
Suction_Line_Size 7/8
Compressor_Motor_TypeScroll
Condenser_Fan_Motor_TypeDirect Drive
Condenser_Fan_Motor_Hp 1/3
Condenser_Fan_Motor_Rpm825
Metering_DeviceTXV
Auxiliary_Heater_IncludedNo
Auxiliary_Heater_AvailableYes
Auxiliary_Heater_Sizes7.5kw, 10kw, 15kw, 20kw
Ul_ReconizedNo
Ul_ListedNo
Etl_ListedYes
Etl_CertifiedNo
Leed_CertifiedNo
Energy_Star_CompliantNo
Energy_Star_CertifiedNo
Ahri_CertifiedYes
Registered_WarrantyRegistered 10 Year Parts Warranty
Base_Warranty5 Year Parts Warranty
Registered_Parts_WarrantyRegistered 10 Year Parts Warranty
Base_Parts_Warranty5 Year Parts Warranty
Has_BatteriesNo
Contains_ElectronicsYes
Contains_ChemicalsYes
Contains_AerosolYes
Contains_Compressed_GasYes
Proposition_65_WarningYes
Restricted_StatesNo
