capacity:
60000 BTU
category:
Heating & Air Conditioning System Component
manufacturer:
MRCOOL
mpn:
MMBV20DE
product_color:
Gray
series:
Signature Modular Blower
subcategory:
Modular Blower
Product Overview
5 Ton Multi-Positional Variable Speed Modular Blower
The MRCOOL Multi-Position Modular Blower is designed to deliver dependable comfort, and is built for reliability. The electronically commutated motor (ECM) delivers consistent airflow throughout the seasons, allowing you to remain relaxed at all times. When choosing a MRCOOL Multi-Position Modular Blower, you can always know that you are being energy and time efficient.
Features:
- Cabinet dimensions match standard furnace widths
- Painted galvanized cabinet
- ECM variable speed motors
- Field installed 5-20 kW heat strips
- Factory installed fan relays for non-heat strip installations
- 10 year limited parts warranty
- ETL and ETLC approved
- AHRI certified
- Variable speed blower motor
- Upflow, counterflow, and horizontal configurations
- Approved for installation in manufactured housing and mobile homes
Additional Information
Series_Extmmbv
Unit_TypeModular Blower
Net_Depth24.5
Net_Height26
Net_Width21
Net_Weight105
ConfigurationUpflow, counterflow, and horizontal
Cfm1780
Tonnage5
Cooling_Capacity560-1780
Voltage208-230
Phase1
Cycle60
Max_Fuse_Breaker15
Min_Circuit_Ampacity0
ColorGray
Color_FamilyGray
Max_Coverage_Area2500
Refrigerant_TypeR-410A
Number_Of_SpeedsVariable
InverterNo
Blower_Motor_TypeECM
Blower_Motor_Hp 3/4
Blower_Motor_SpeedsVariable Speed
Filter_TypeReplaceable
Filter_Size20x30(2)
Auxiliary_Heater_Sizes15kw
Ul_ReconizedNo
Ul_ListedNo
Etl_ListedYes
Etl_CertifiedNo
Iso_CertifiedNo
Leed_CertifiedNo
Energy_Star_CompliantNo
Energy_Star_CertifiedNo
Ahri_CertifiedYes
Registered_Warranty10 Year Limited Parts Warranty
Registered_Parts_Warranty10 Year Limited Parts Warranty
Has_BatteriesNo
Contains_ElectronicsYes
Contains_ChemicalsYes
Contains_AerosolYes
Contains_Compressed_GasYes
Proposition_65_WarningYes
Restricted_StatesNo
